11739794-1-M-Whirlpool-WP2223320-Refrigerator Pan Slide Track
Part Location Diagram of WP2223320 Whirlpool Refrigerator Pan Slide Track
See part 4 in the diagram
Replacing your Whirlpool Refrigerator Refrigerator Pan Slide Track
11739794-1-S-Whirlpool-WP2223320-Refrigerator Pan Slide Track 360 view
( Grid squares measure 1x1 inch )
11739794-1-S-Whirlpool-WP2223320-Refrigerator Pan Slide Track 11739794-2-S-Whirlpool-WP2223320-Refrigerator Pan Slide Track 11739794-1-S-Whirlpool-WP2223320-Refrigerator Pan Slide Track 360 view
Part Location Diagram of WP2223320 Whirlpool Refrigerator Pan Slide Track Replacing your Whirlpool Refrigerator Refrigerator Pan Slide Track

Refrigerator Pan Slide Track WP2223320

Rated by 15 customers

?

Really Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

?
$23.09
In Stock
Fix Number:
FIX11739794
Manufacturer #:
WP2223320
Manufactured by:
Whirlpool

Jump to:

Product Description

The pan slide track allows the drawer (also called a snack pan) to slide in and out easily. If the drawer does not easily pull out or push back in, the slide track may be damaged and need to be replaced. Too much weight in the pan or on the shelf may be the cause of this damage. Replacing this part is simple and does not require any tools to complete the repair. Remove both the snack pan and the shelf from the fridge, and place the shelf on a solid surface, being careful not to put excess pressure on the glass shelf. Then remove the damaged track by unlocking the pins and the tabs from their holder. Line up the new track, and push into place until it locks. Place the shelf back into your fridge, and the snack pan should now easily slide into place. Please note that these tracks are sold individually but can be used on both the right and left sides of the shelf. This is a genuine OEM part, that is white in color and measures approximately 12 inches in length.

  • Works with the following brands:
    Whirlpool, Kenmore
  • Works with the following products:
    Refrigerator
  • Fixes the following symptoms:
    Door won’t open or close, Ice maker not making ice, Ice maker won’t dispense ice
  • Part# WP2223320 replaces these:
    AP6006718, 2223320, WP2223320VP
Works with the following brands:
Whirlpool, Kenmore
Works with the following products
Refrigerator
Fixes the following symptoms
Door won’t open or close, Ice maker not making ice, Ice maker won’t dispense ice
Part Number Cross Reference
Part# WP2223320 replaces these:
AP6006718, 2223320, WP2223320VP

Videos For installing this part.

Replacing your Refrigerator Pan Slide Track

Replacing your Refrigerator Pan Slide Track

Questions and Answers

Be the first to ask our experts a question about this part!

Washer Affresh Cleaner
$12.54
In Stock
Part Number: FIX1960673
This front load washer cleaner removes odor-causing residue. Use it once a month and it will keep your machine fresh and clean. Package comes with 3 tablets.
Cleaner
$18.43
In Stock
Part Number: FIX12346712
This cooktop cleaning kit includes a scraper and scrub pad that remove build-up and cooked-on spills without scratching or harming your cooktop surfaces and a non-abrasive cleaner that is safe for all glass and ceramic c...
Appliance Cleaner
$23.93
In Stock
Part Number: FIX16227489
This cleaner is ideal for ventilation, microwaves, cooktops, refrigeration, and stainless steel surfaces. It easily removes burnt-on debris and greasy residues. Can be used on kitchen cabinets, countertops, tile and stee...
Affresh Dishwasher Cleaner Tablets - 6
$19.04
In Stock
Part Number: FIX12345667
Affresh dishwasher Cleaner is specially formulated to help remove limescale and mineral build-up that can be unsightly and could affect your dishwasher's performance. Each tablet is designed to clean inside your machine ...
Scratch B Gone Stainless Steel Scratch Remover Kit
$126.64
In Stock
Part Number: FIX2340672
This product permanently removes scratches, stains and rust from all brushed surfaces on stainless steel appliances, grills, sinks and more. This is for use on true stainless steel products only
Stainless Steel Cleaner
$15.56
In Stock
Part Number: FIX12717775
Our scratch-free, streak-free formula removes fingerprints, smudges, grease, dirt and oil, while protecting and polishing to repel dust and dirt. Use on all stainless steel appliance brands and surfaces. Stainless Steel ...

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 4.4 / 5.0, 15 reviews.
  • 1
  • 2
Sort by:
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
Customer:
Ray from Camano Island, WA
Parts Used:
WP2223320
Difficulty Level:
Easy
Total Repair Time:
Less than 15 mins
slide end broke off
I just used a hammer to tap the slide out and then in the slots. I found the second one cracked by time I got the new one so be sure to buy both. It took about three weeks to get part but price was worth it compare to other online places.
2 of 2 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Patricia from Sacramento, CA
Parts Used:
WP2223320
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Lunch meat drawer rails broke, causing drawer to fall out
1.cleaned off shelves 2.removed drawer, removed shelf with rails. 3.the old rails slid out easily 4.the new rails had an extra set of nubs that had to be ground off, once they were removed new rails slid right in with a little pressure and push. 5.replaced shelf and slid drawer right in.
Read less
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Brian from San marcos, CA
Parts Used:
WP2223320
Difficulty Level:
A Bit Difficult
Total Repair Time:
15 - 30 mins
drawer sagging when open do to Broken track
Tack out drawer,take out rack assy. Slide old track out. the new track just slides into cut outs of shelf mounts. My new track had some plastic islands/bumps that made it too tight to get in. I shaved down necessary areas until it went together.
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
BERNARD from Lusby, MD
Parts Used:
W10233485, WP2223320
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
Slide track and pan handle were plastic and had broken
Removed and replaced broken parts with new parts
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
nancy from sidney center, NY
Parts Used:
WP2223320, WP2156022
Difficulty Level:
Very Easy
Total Repair Time:
Less than 15 mins
Tools:
Nutdriver, Screw drivers
broke my top shelf holder on the refrig and track on shelf after getting the right part
Took a screwdriver and bibby boop da day and it was fixed anyone could do it took less than 5 minutes
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Randy from Fullerton, CA
Parts Used:
WP2223320
Difficulty Level:
Very Easy
Total Repair Time:
Less than 15 mins
Side bracket replacement for vegetable drawer
No tools needed. Took longer to unload the shelf than to do the job. As easy as the video indicated.
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Gary from Austin, IN
Parts Used:
WP2223320
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Pinched my thumb
Taking the old part out it pinched my thumb when trying to slide it out. The new part went in very easy with no problems. The hardest part was cleaning off the shelf so I could remove it to install the new parts.
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Tom from Manchester, NJ
Parts Used:
WP2223320
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
pan slide track broken
I used a tack hammer to remove old slide track. Tapped it out gently rather than pushing out using my fingers. Next I used a file to sand down 2 nubs that protrude. Compare visually to broken part being replaced and you'll see how much to sand down. Line up new slide and use tack hammer at front of slide to tap into position. Should pop in with little to no force.
Read less
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
MATT from WEATOGUE, CT
Parts Used:
WP2223320
Difficulty Level:
Really Easy
Total Repair Time:
Less than 15 mins
cracked slide tracks
very easy, pulled drawer out, pulled shelf out, used hole punch to depress nipple then slid track out. lined up new track and tapped in place with rubber mallet
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Customer:
Rick from Fort Worth, TX
Parts Used:
WP2223320
Difficulty Level:
Difficult
Total Repair Time:
30 - 60 mins
The buttons didn't correspond to the button location on the shelf metal arms
Filed down the buttons in order to seat the pan slide tracks.
0 of 1 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1
  • 2

Model Compatibility

This part works with the following models:
Fix Number: FIX11739794
Manufacturer Part Number: WP2223320
Brand Model Number Description
Kenmore 10641522500 Refrigerator
Kenmore 10641523500 Refrigerator
Kenmore 10641524500 Refrigerator
Kenmore 10641529500 Refrigerator
Kenmore 10644322400 Refrigerator
Kenmore 10644323400 Refrigerator
Kenmore 10644324400 Refrigerator
Kenmore 10644329400 Refrigerator
Kenmore 10654202300 Refrigerator
Kenmore 10654203300 Refrigerator
Kenmore 10654204300 Refrigerator
Kenmore 10654206300 Refrigerator
Kenmore 10654209300 Refrigerator
Kenmore 10654212300 Refrigerator
Kenmore 10654213300 Refrigerator
Kenmore 10654214300 Refrigerator
Kenmore 10654216300 Refrigerator
Kenmore 10654219300 Refrigerator
Kenmore 10654602300 Refrigerator
Kenmore 10654603300 Refrigerator
Kenmore 10654604300 Refrigerator
Kenmore 10654606300 Refrigerator
Kenmore 10654609300 Refrigerator
Kenmore 10654612300 Refrigerator
Kenmore 10654613300 Refrigerator
Kenmore 10654614300 Refrigerator
Kenmore 10654616300 Refrigerator
Kenmore 10654619300 Refrigerator
Kenmore 10655202400 Refrigerator
Kenmore 10655203400 Refrigerator
